The IRIS electromagnetic sieve shakers are used in research and development, and in quality control for production processes, both for raw materials and intermediate and finished products.
With them it is possible to carry out granulometric testing for particle separation, both for dry and wet conditions.
The IRIS model sieve shakers are highly effective, thanks to the three-dimensional particle motion, created by an electromagnet. With this 3D effect the particles bounce over the whole sieve area, forcing them to pass through to the lower sieve more quickly. Thus a faster, more effective sieving is achieved through the whole
sieve column.
IRIS FTL0200 SIEVE SHAKER
Digital electromatic sieve shaker for
sieves from Ø 60 a 203 mm. Its
three-dimensional movement throughout
the sieve column makes it very effective
when carrying out granulometric test.
It includes digital power, timing and
intermittence controls for sieving. It
can be supplied with the standard
anchoring system or with the “Easy-
Press” rapid system. It permits 8 sieves
of 50 mm in height, or 16 sieves of 25
mm in height.
STANDARD BAKELITE
THREADED KNOBS WITH
METHACRYLATE LID
EASY PRESS KNOBS
PRESSURIZED TIGHTENING
KNOBS WHICH SLIDE EASILY
ALONG THE RODS, WITH
METHACRYLATE LID
Small, compact and light, it is the
economic option from the IRIS range
of electromagnetic sieves. Allows
sieves from Ø 60 to 203 mm Up to 7
sieves of 50 mm in height, or 14 sieves
of 25 mm in height. It includes digital
power, timing and intermittence
controls for sieving. It is supplied with
the standard fixation system.
IRIS FTS0200 SIEVE SHAKER
Designed for high sample volumes,
it can admit 5 sieves of 80 mm in
height, or 8 sieves of 50 mm in height.
The diameters range from 250 to
305 mm. The power, time of sieving
and intermittence are all digitally
adjusted.
It can be supplied with the standard
fixation system or with the “Easy-
Press” rapid system, according to
your choice.
IRIS FTL0300 SIEVE SHAKER
IRIS FTL0400 SIEVE SHAKER
It allows a large load capacity.
It is designed for sieves from Ø
400 mm, although it can also
allow smaller diameters. With
the highly effective 3D motion,
sieving times are short; even with
large product samples. Like the
other models, it includes digital
power, timing and intermittence
controls for sieving.
It is possible to choose between
the standard anchoring system
and the “Easy-Press” rapid
system.
